Isc Cables

Isc Cables
Isc Cables
Product Code : 25
Product Description

We are an eminent organization engaged in manufacturing, trading and exporting a wide range of ISC Cables. Extensively used in trolleys, cranes, furnaces and other heavy duty applications, these are ethylene propylene rubber cables, which are developed using high-grade copper and basic material that is obtained from the reliable vendors of the market. Provided in different specifications, these cables are thoroughly tested on various parameters to ensure flawlessness. The ISC Cables offered by us are available at industry leading prices.

ISC Cables

ISC introduces flexible cables for use in cranes, furnaces, trollies and other heavy duty applications. These flexible EPR (Ethylene propylene rubber) cables have fine stranded tinned copper conductor of electrolytic grade. ISC manufactures these cables to BIS, BS and DIN standards. These cables are designed and manufactured in a controlled manufacturing process to get the best possible results.

All electrical cables are somewhat flexible, allowing them to be shipped to installation sites wound on reels or drums. Where applications require a cable to be moved repeatedly, such as for portable equipment, more flexible cables called "cords" or "flex" are used. Flexible cords contain fine stranded conductors, not solid core conductors, and have insulation and sheaths to withstand the forces of repeated flexing and abrasion. Heavy duty flexible power cords such as those feeding a mine face cutting machine/ Electrical Over Head Traveling Cranes are carefully engineered—their life is measured in weeks. Very flexible power cables are used in automated machinery, robotics, and machine tools. See power cord and extension cable for further description of flexible power cables. Other types of flexible cable include twisted pair, extensible, coaxial, shielded, and communication cable.

Ethylene propylene rubber (EPR) is an insulation used for high voltage cables. It has improved thermal characteristics over more traditional cables, such as crosslinked polyethylene, enabling a smaller cross sectional area for the same load carrying capacity. The cable is flexible and suited to applications where regular cable movement is required such as in the mining/ steel industry and for temporary installations.

With regard to the frequent failures of electrical cables ISC recommends that the cable specifications be changed keeping the current carrying capacity of existing cables. In the past and presently it is noticed that TRS cables are being used whereas TRS cables have long given way to EPR cables. TRS cables have natural rubber as their external and load bearing and insulating layers. Rubber over a period of time becomes hard and dry and in the process brittle thus cracks appear on the cables and the insulation covering breaks down. As the rubber insulation breaks down the load bearing capacity of the cable is directly transferred to current bearing cores thus causing breakage and shorting.

This can be over come by gradually changing the existing cables from TRS to EPR 1.1 KV Grade Flexible Cable, Annealed tinned copper conductor, EPR (ethylene propylene rubber) insulated, Cores laid-up together suitably PCP (poly chloroprene (neoprene)) Outer sheathed. Cable, Conforming to IS: 9968/Pt-1/88. Further more these EPR cables can with stand much higher temperatures and these cables are made to order and solid flexible load carrying members embedded in the cables and these load bearing members can be used for anchoring cables thus enabling the power carrying members to be free from any load and thus failing.
